3.1 Pre-Operation Inspection
60
Inspection
Procedure
1. Clip the resistor with the red and black
test leads connected to the instrument.
2. Also, clip the resistor with the test lead of
the high-voltage meter.
3. Set the test voltage of the instrument to
[5.00 kV].
See 3.2Measuring Insulation Resistance, Proce-
dure 5. (page 66) to (page 66).
4. Hold down key for more than
one second to start insulation resistance
measurement.
5.
Check to see if the reading of the high-volt-
age meter is somewhere between 5 kV and
5.5 kV.
6. Check to see if the voltage reading of the
instrument is somewhere between 5 kV
and 5.5 kV.
To Next Page
