100
Input Specications, Output Specications, and Measurement Specications
1500 V 100 G
Ω
0.00 M
Ω
to 20.0 G
Ω ±
5% rdg
±
5 dgt
20.1 G
Ω
to 100 G
Ω ±
20% rdg
Range conguration (auto range)
Range Display range Resolution
10 M
Ω
0.00 M
Ω
to 9.99 M
Ω
0.01 M
Ω
100 M
Ω
9.0 M
Ω
to 99.9 M
Ω
0.1 M
Ω
1000 M
Ω
90 M
Ω
to 999 M
Ω
1 M
Ω
10 G
Ω
0.90 G
Ω
to 9.99 G
Ω
0.01 G
Ω
100 G
Ω
9.0 G
Ω
to 99.9 G
Ω
0.1 G
Ω
90 G
Ω
to 100 G
Ω
1 G
Ω
E󰀨ect of supplied
voltage
Accuracy
×
0.5 and within accuracy specications
E󰀨ect of temperature Accuracy
×
1.0 is added to the accuracy (applicable in the ambient
temperature range excluding 18
°
C to 28
°
C)
E󰀨ect of capacitance
component
Within
±
10% rdg at a capacitance of 5 µF or less (including drift)
Number of possible
measurements
1000 or more
Overload protection 1100 V AC (for 10 sec. between + & − terminals)
6000 V DC (for 10 sec. between + & − terminals)
Display update Once/sec. or more
Response time Measurement condition: Resistive load
(output voltage 1500 V, resistive load 80 G
Ω
)
Within 4 sec.
HIOKI IR5050A961-00
