Input Specications, Output Specications, and Measurement Specications
(4) Capacitance measurement
Accuracy guarantee
range
10.0 nF to 25.0 μF
Accuracy
±
10% rdg
±
5 nF
Range conguration (auto range)
Range Display range Resolution
100 nF 0.0 nF to 99.9 nF 0.1 nF
1000 nF 100 nF to 999 nF 1 nF
10 μF
1.00 μF to 9.99 μF
10.0 μF to 25.0 μF
0.01 μF
0.1 μF
E󰀨ect of temperature Accuracy
×
1.0 is added to the accuracy (applicable in the ambient
temperature range excluding 18
°
C to 28
°
C)
• The capacitance measurement is automatically taken after the insulation resistance
measurement ends.
• The capacitance measurement is not performed if the output voltage is 250 V or less during
the insulation resistance measurement. The instrument will display [---] as the capacitance if it
is unable to perform capacitance measurement.
(5) PV insulation resistance measurement
Output voltage Output voltage range 250 V DC to 2.00 kV DC
Preset test voltage 500 V, 1 kV, 1.5 kV
Setting resolution 250 V to 1 kV
:
10 V steps
1 kV to 2 kV: 25 V steps
Open circuit voltage*
1
−0% and +10% of setting
Lower limit of
resistance that
can maintain rated
measurement voltage
20 M
Ω
Rated current Rated measurement voltage (setting) ÷ rated
measurement voltage that can maintain open
circuit voltage
Short-circuit current 2 mA or less
Output voltage
monitor
Display range 0 V to 5800 V
Accuracy
±
5% rdg
±
5 dgt
Add 5 dgt to the accuracy for the voltage of
30 V or less
*1. PV insulation resistance has approx. 660 k
Ω
of current-limiting resistance on the +
terminal, so the output voltage is divided by 660 k
Ω
and the resistance connected between
the measurement terminals.
Example: When open-circuit voltage is measured with a DMM with an input impedance of
10 M
Ω
, the voltage is divided by 660 k
Ω
and 10 M
Ω
.
Rated measurement
voltage (setting)
Maximum
displayed value
Accuracy guarantee
range
Accuracy (inherent
uncertainty A)
500 V 100 G
Ω
0.00 M
Ω
to 5.00 G
Ω ±
5% rdg
±
5 dgt
5.01 G
Ω
to 100 G
Ω ±
20% rdg
1000 V 100 G
Ω
0.00 M
Ω
to 10.0 G
Ω ±
5% rdg
±
5 dgt
10.1 G
Ω
to 100 G
Ω ±
20% rdg
