Chapter 11 Specifications
152
(10)Comparator Function
(11)Judge delay function
Operation Compares setting and measured values
Setting ON/OFF (fixed range when comparator function is ON)
Comparator mode REF%/ ABS
Default state OFF, ABS mode
Judgment Hi Measured value > Upper limit value
IN Upper limit value ≥ measured value ≥ Lower limit value
Lo Lower limit value > measured value
ABS Mode
Upper/Lower limit
ranges
0.000 m to 9.9999 M
(When the scaling function is on, depends on the scaling display format; max-
imum resolution of 1 n, maximum value of 1 G.)
Default setting 0.000 m
REF% Mode
Display Relative value display
Absolute value display
range
-999.99% to +999.99%
Reference value range 0.001 m to 9.9999 M
(When the scaling function is on, depends on the scaling display format; max-
imum resolution of 1 n, maximum value of 1 G.)
Upper/ Lower limit
ranges
0.00% to ±99.99%
Default setting Reference value: 0.001 m, Upper/ Lower limit ranges: 0.00%
Relative value =
Measured value
Reference value
− 1 × 100 [%]
Operation After recovering from current fault (after making contact with the measurement
leads), no judgments for measurement values are performed the same times
as the number of unjudged measurements, and a judgment begins from next
measurement.
Setting ON/ OFF (Available only when the auto-hold is set to OFF, the internal trigger
source is selected and the continuous measurement is set to ON [Free-Run].)
The number of unjudged
measurements
1 to 100times
