Hirschmann BRS20-0400 Series User Manual

Installation BRS20/30/40/50
Release 02 11/2018
35
1.6.2 Port status
These LEDs display port-related information.
Note:
 For device variants with 4 × RJ45 sockets:
The LEDs are directly located at the ports.
See figure 3 on page 35.
 For device variants with 8 × RJ45 sockets:
The LEDs are located on the right side of the device.
See figure 4 on page 36.
See figure 5 on page 36.
 For device variants with ports that are DSC/DST sockets and SFP slots:
The LEDs are directly located at the ports.
See figure 4 on page 36.
See figure 5 on page 36.
Figure 3: LED display elements for device variants with 4 × RJ45 sockets
1
1
2
3
4
1
1
2
3
4
2
2
3
3
4
4
LS/DA
-
-
-
-
-
-
-
-
-
