Installation BRS20/30/40/50
Release
02
11/2018
39
Voltage not potential-separated
Supported file system: FAT32
Note: A USB cable is used exclusively for the configuration of your device.
Note:
The ACA22-USB-C (EEC) storage medium can remain permanently
connected to the device.
1.7.3 Digital input
Figure 8: (1) Connection on the device, (2) terminal block mounted on the device
(front view), tightening torque.
The digital input allows you to capture and forward signals from digital
sensors. In the configuration, you specify how the device uses the digital
input.
You will find detailed information on possible applications and the
configuration of the digital input in the software user documentation on the
Hirschmann product pages (www.hirschmann.com).
