Installation BRS20/30/40/50
Release
02
11/2018
57
6.5 Digital input
Digital input
Connection type 2-pin terminal block with screw lock
Tightening torque 4.4 lb-in (0.5 Nm)
min. conductor
diameter
0.08 mm
2
(AWG 28)
max. conductor
diameter
AWG12 (2.5 mm²)
Supply voltage range -32 V DC ... +32 V DC
Nominal input voltage +24 V DC
Input voltage, low level, status “0” -0.3 V DC … +5 V DC
Input voltage, high level, status “1” +11 V DC … +30 V DC
Maximum input current at nominal input
voltage
15 mA
Permitted closed-circuit current for 2-wire
sensors
1.5 mA
Input characteristic according to IEC 61131-2
(current-consuming)
Typ 3
Table 14: Digital input
