Hirschmann BRS20-0400 Series User Manual

56
Installation BRS20/30/40/50
Release 02 11/2018
6.3 Power consumption/power output
6.4 Signal contact
Device name Maximum power
consumption
Power output
BRS20-0400... 5 W 17 Btu (IT)/h
BRS20-0500... 6 W 20 Btu (IT)/h
BRS20-0600... 7 W 24 Btu (IT)/h
BRS20-0800... 6 W 20 Btu (IT)/h
BRS20-0900... 7 W 24 Btu (IT)/h
BRS20-1000... 8 W 27 Btu (IT)/h
BRS20-1100... 9 W 31 Btu (IT)/h
BRS20-1200... 9 W 31 Btu (IT)/h
BRS30-0804... 9 W 31 Btu (IT)/h
BRS40-0008... 8 W 27 Btu (IT)/h
BRS40-0012... 11 W 38 Btu (IT/h)
BRS50-0012... 12 W 41 Btu (IT)/h
Table 12: Power consumption/power output
Signal contact
Device variants featuring supply voltage with characteristic value F and T
Connection type 6-pin terminal block with screw lock
Tightening torque 4.4 lb-in (0.5 Nm)
min. conductor diameter 0.08 mm
2
(AWG 28)
max. conductor diameter AWG12 (2.5 mm²)
Nominal value I
max
=1A at U
max
=30VAC
I
max
=1A at U
max
=60VDC
according to the UL Standards:
I
max
=0.5A at U
max
=30VAC
I
max
=1A at U
max
=30VDC
as per ANSI/UL 121201:
See control drawing in section
“Relevant for use in explosion hazard areas (Hazardous
Locations, Class I, Division 2)” on page 10
Table 13: Signal contact: device variants featuring supply voltage with characteristic
valueF andT
