Hirschmann BRS20-0400 Series User Manual

18
Installation BRS20/30/40/50
Release 02 11/2018
1.2 Device name and product code
The device name corresponds to the product code. The product code is
made up of characteristics with defined positions. The characteristic values
stand for specific product properties.
You have numerous options of combining the device characteristics. You can
determine the possible combinations using the Configurator which is
available in the Belden E-Catalog (www.e-catalog.beldensolutions.com) on
the web page of the device.
Item Characteristic Character
istic value
Description
1 ... 3 Product BRS BOBCAT Rail Switch
4 Data rate 2 100 Mbit/s
3 100/1000 Mbit/s
4 1000 Mbit/s
5 1000/2500 Mbit/s
5 Hardware type 0 Standard
6 (hyphen) –
7 ... 8 Number:
100 Mbit/s ports
00 0 × 10/100 Mbit/s ports
04 4 × 10/100 Mbit/s ports
05 5 × 10/100 Mbit/s ports
06 6 × 10/100 Mbit/s ports
08 8 × 10/100 Mbit/s ports
09 9 × 10/100 Mbit/s ports
10 10 × 10/100 Mbit/s ports
11 11 × 10/100 Mbit/s ports
12 12 × 10/100 Mbit/s ports
9 ... 10 Number:
100/1000/
2500 Mbit/s ports
00 0 × 100/1000 Mbit/s ports
04 4 × 100/1000 Mbit/s ports
08 8 × 100/1000 Mbit/s ports
12 12 × 100/1000 Mbit/s ports
12 12 × 8 × 100/1000-Mbit/s-Ports + 4 × 100/1000/
2500 Mbit/s
Table 1: Device name and product code
