Hirschmann BRS20-0400 Series User Manual

Installation BRS20/30/40/50
Release 02 11/2018
19
11 ... 12 Configuration of
the first uplink
ports
99 Not present
M2 1 × DSC multimode socket for 100 Mbit/s F/O
connections
M4 1 × DST multimode socket for 100 Mbit/s fiber optic
connections
S2 1 × DSC singlemode socket for 100 Mbit/s F/O
connections
S4 1 × DST singlemode socket for 100 Mbit/s fiber optic
connections
E2 1 × DSC singlemode (plus) socket for 100 Mbit/s fiber
optic connections
L2 1 × DSC singlemode (LH) socket for 100 Mbit/s fiber optic
connections
G2 1 × DSC singlemode (LH) socket for 100 Mbit/s fiber optic
connections, 200 km
Z6 1 × SFP slot for 100 Mbit/s F/O connections
MM 2 × DSC multimode socket for 100 Mbit/s F/O
connections
NN 2 × DST multimode socket for 100 Mbit/s fiber optic
connections
VV 2 × DSC singlemode socket for 100 Mbit/s F/O
connections
UU 2 × DST singlemode socket for 100 Mbit/s fiber optic
connections
EE 2 × DSC singlemode (plus) socket for 100 Mbit/s fiber
optic connections
LL 2 × DSC singlemode (LH) socket for 100 Mbit/s fiber optic
connections
GG 2 × DSC singlemode (LH) socket for 100 Mbit/s fiber optic
connections, 200 km
ZZ 2 × SFP slot for 100 Mbit/s F/O connections
OO 2 × SFP slot for 100/1000 Mbit/s F/O connections
2Q 2 × SFP slot for 100/1000/2500 Mbit/s fiber optic
connections
Item Characteristic Character
istic value
Description
Table 1: Device name and product code
