54
Installation BRS20/30/40/50
Release
02
11/2018
6 Technical data
6.1 General data
6.2 Supply voltage
General data
Weight BRS20-0400... 12.22 oz (380 g)
BRS20-0500... 14.82 oz (420 g)
BRS20-0600... 14.82 oz (420 g)
BRS20-0800....S;C... 14.82 oz (420 g)
BRS20-0800....T;E... 17.64 oz (500 g)
BRS20-0900....S;C... 17.64 oz (500 g)
BRS20-0900....T;E... 20.10 oz (570 g)
BRS20-1000....S;C... 17.64 oz (500 g)
BRS20-1000....T;E... 20.10 oz (570 g)
BRS20-1100....S;C... 17.64 oz (500 g)
BRS20-1100....T;E... 20.10 oz (570 g)
BRS20-1200....S;C... 17.64 oz (500 g)
BRS20-1200....T;E... 20.10 oz (570 g)
BRS30-0804... 20.10 oz (570 g)
BRS40-0008... 17.64 oz (500 g)
BRS40-0012... 20.10 oz (570 g)
BRS50-0012... 20.10 oz (570 g)
Dimensions
W × H × D
See “Dimension drawings” on page 59.
Mounting See “Installing the device onto the DIN rail” on page 40.
Pollution degree 2
Degree of protection IP30
Laser protection Class 1 in compliance with IEC 60825-1
Table 9: General data
Supply voltage with characteristic value T
Rated voltage range DC: 12 V DC ... 24 V DC
Voltage range DC incl. maximum
tolerances:
9.6VDC...32VDC
Table 10: Supply voltage with characteristic value T
