Installation BRS20/30/40/50
Release
02
11/2018
59
6.8 Dimension drawings
Figure 20: Device variants with max. 6 ports
57
2.24
137,5
5,3
50,4
35,6
103,5
12,3
14,9
0.59
5.410.21
4.07
5
0.2
0.48
1.4
1.97
mm
inch
