70
Installation BRS20/30/40/50
Release
02
11/2018
a - By using a SFP transceiver without “EEC” extension, the temperature of the device is reduced by 15 K.
6.12.2 Gigabit Ethernet SFP transceiver
M-FAST SFP-LH/LC EEC 0 K 0 K 943 948-001
M-FAST SFP-TX/RJ45 0 K a 942 098-001
M-FAST SFP-TX/RJ45 EEC 0 K 0 K 942 098-002
SFP-FAST-MM/LC 0 K a 942 194-001
SFP-FAST-MM/LC EEC 0 K 0 K 942 194-002
SFP-FAST-SM/LC 0 K a 942 195-001
SFP-FAST-SM/LC EEC 0 K 0 K 942 195-002
Product code Derating for a device with max.
operating temperature +140 °F
(+60 °C) per SFP transceiver used
Derating for a device with max.
operating temperature +158 °F
(+70 °C) per SFP transceiver used
Order number
M-SFP-SX/LC 0 K a 943 014-001
M-SFP-SX/LC EEC 0 K 0 K 943 896-001
M-SFP-LX/LC 0 K a 943 015-001
M-SFP-LX/LC EEC 0 K 0 K 943 897-001
M-SFP-LH/LC 2 K a 943 042-001
M-SFP-LH/LC EEC 0 K 2 K 943 898-001
M-SFP-LH+/LC 2 K a 943 049-001
M-SFP-TX/RJ45 3 K a 943 977-001
M-SFP-TX/RJ45 EEC 0 K 3 K 942 161-001
SFP-GIG-LX/LC 0 K a 942 196-001
Table 28: Derating due to Gigabit Ethernet SFP transceiver
Product code Derating for a device with operating
temperature +140 °F (+60 °C) per SFP
transceiver used
Derating for a device with operating
temperature +158 °F (+70 °C) per SFP
transceiver used
Order number
Table 27: Derating due to Fast Ethernet SFP transceiver
