20
Installation BRS20/30/40/50
Release
02
11/2018
13 ... 14 Configuration of
the second uplink
ports
99 Not present
M2 1 × DSC multimode socket for 100 Mbit/s F/O
connections
M4 1 × DST multimode socket for 100 Mbit/s fiber
optic connections
S2 1 × DSC singlemode socket for 100 Mbit/s F/O
connections
S4 1 × DST singlemode socket for 100 Mbit/s fiber
optic connections
E2 1 × DSC singlemode (plus) socket for 100 Mbit/
s fiber optic connections
L2 1 × DSC singlemode (LH) socket for 100 Mbit/s
fiber optic connections
G2 1 × DSC singlemode (LH) socket for 100 Mbit/s
fiber optic connections, 200 km
Z6 1 × SFP slot for 100 Mbit/s F/O connections
ZZ 2 × SFP slot for 100 Mbit/s F/O connections
OO 2 × SFP slot for 100/1000 Mbit/s F/O
connections
2Q 2 × SFP slot for 100/1000/2500 Mbit/s fiber
optic connections
15 (hyphen)
16 Temperature
range
S Standard +32 °F ... +140 °F (0 °C ...
+60 °C)
C Standard
with Conformal
Coating
+32 °F ... +140 °F (0 °C ...
+60 °C)
T Extended 40 °F ... +158 °F (40 °C ...
+70 °C)
E Extended
with Conformal
Coating
40 °F ... +158 °F (40 °C ...
+70 °C)
17 Supply voltage T 2 × 12 V DC ... 24 V DC
F 2 × 24 V DC ... 48 V DC / 24 V AC
18 Housing IP30 Plastic
19 Certificates and
declarations
Part A
a
Z CE, FCC, EN 61131, EN 62368-1
Y Z + cUL61010
X cUL61010 + ANSI/UL 121201
U Z + DNVGL
W Z+ATEX/IECEx
T Z + EN 50121
20 Certificates and
declarations
Part B
b
9 Not present
Y cUL61010
X cUL61010 + ANSI/UL 121201
U DNV GL
W ATEX/IECEx
T EN 50121
Item Characteristic Character
istic value
Description
Table 1: Device name and product code
