62
Installation BRS20/30/40/50
Release
02
11/2018
EMC interference immunity Standard
applications
a
a. EN 61131-2, CE, FCC – applies to all devices
Navy
applications
Railway
applications
(trackside) as per
EN 50121-4
Electrostatic discharge
EN 61000-4-2 Contact discharge ±4 kV ±6 kV ±6 kV
EN 61000-4-2 Air discharge ±8 kV ±8 kV ±8 kV
Electromagnetic field
EN 61000-4-3 80 MHz ... 800 MHz — — 10 V/m
80 MHz ... 1000 MHz 10 V/m — —
800 MHz ... 1000 MHz — — 20 V/m
80 MHz ... 2000 MHz — 10 V/m —
1.4 GHz ... 2.0 GHz 3 V/m — 10 V/m
2.0 GHz ... 2.7 GHz 1 V/m — 5 V/m
5.1 GHz ... 6.0 GHz — — 3 V/m
Fast transients (burst) – power supply connection
EN 61000-4-4 ±2 kV ±2 kV ±2 kV
Fast transients (burst) – data line
EN 61000-4-4 ±1 kV ±1 kV ±2 kV
Voltage surges – power supply connection
EN 61000-4-5 line/ground ±2 kV ±1 kV ±2 kV
EN 61000-4-5 line/line ±1 kV ±0.5 kV ±1 kV
Voltage surges - data line
EN 61000-4-5 line/ground ±1 kV — ±2 kV
Conducted disturbances
EN 61000-4-6 150 kHz ... 80 MHz 10 V 10 V 10 V
Table 19: EMC interference immunity
