Hirschmann BRS20-0400 Series User Manual

64
Installation BRS20/30/40/50
Release
02
11/2018
-LH/LC... SM 1550 nm 9/125 µm 10 dB ... 29 dB 29.20 mi ...
64.62 mi (47 km ...
104 km)
0.25 dB/km 19 ps/(nm×km)
-LH/LC... SM 1550 nm 9/125 µm 10 dB ... 29 dB 14.29 mi ...
86.99 mi (55 km ...
140 km)
0.18 dB/km
c
18 ps/(nm×km)
a. MM = Multimode, SM = Singlemode, LH = Singlemode Longhaul
b. Including 3 dB system reserve when compliance with the fiber data is observed.
c. With ultra-low-loss optical fiber.
Product code Mode
a
Wave length Fiber System
attenuation
Example for F/O
cable length
b
Fiber attenuation BLP/Dispersion
-M2, -MM MM 1300 nm 50/125 µm 0 dB ... 8 dB 0 mi ... 3.11 mi
(0 km ... 5 km)
1.0 dB/km 800 MHz×km
-M2, -MM MM 1300 nm 62.5/125 µm 0 dB ... 11 dB 0 mi ... 2.49 mi
(0 km ... 4 km)
1.0 dB/km 500 MHz×km
-M4, -NN SM 1300 nm 62.5/125 µm 0 dB ... 11 dB 0 mi ... 2.49 mi
(0 km ... 4 km)
1.0 dB/km 500 MHz×km
-S2, -VV SM 1300 nm 9/125 µm 0 dB ... 16 dB 0 mi ... 18.64 mi
(0 km ... 30 km)
0.4 dB/km 3.5 ps/(nm×km)
-S4, -UU SM 1300 nm 9/125 µm 0 dB ... 16 dB 0 mi ... 18.64 mi
(0 km ... 30 km)
0.4 dB/km 3.5 ps/(nm×km)
-E2, EE SM+ 1300 nm 9/125 µm 7 dB ... 29 dB 12.43 mi ...
40.39 mi (25 km ...
65 km)
0.4 dB/km 3.5 ps/(nm×km)
Table 22: F/O port 100BASE-FX (DSC/DST fiber optic Fast Ethernet Transceiver)
Product code
M-FAST-SFP-...
Mode
a
Wave length Fiber System
attenuation
Example for F/O
cable length
b
Fiber attenuation BLP/Dispersion
Table 21: Fiber port 100BASE-FX (SFP fiber optic Fast Ethernet Transceiver)
