Hirschmann Manitex vSCALE D3 - Understanding Functional Elements

Operation
5.1 Functional elements
Function keys F1 to F12: for calling operating functions
Light sensor: measures the ambient brightness for controlling the background lighting
Operating display: shines green when the supply voltage is connected
USB data display: shines yellow when data is exchanged via the front USB interface
Status display: (no function here)
Multi-function light, coloured: (no function here)
Encoder with pushbutton function: for selection and confirmation when making inputs
Function key (System): (no function here)
Function key (Home): calls up the SLI main menu:
Function key (Esc): (no function here)
