Operation
5.10.3 Status of digital outputs
The system incorporates an Info menu in which the status of the digital inputs can be called up:
Calling up the menu
from the INFO menu:
Back to INFO menu
If green:
List of digital outputs in use
Digital output is active
Status of digital output
Press the “HOME” function key to call up the SLI main menu:
© 2012 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.hirschmann.com 48/59
50-700-19-2001_422175_en (Manitex)_Rev_B.doc / 2012-03-13 / Issue B / rk.
