Hirschmann qSCALE i2 Service Manual

Troubleshooting
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 17/161
qSCALE i2 Cranes (Tool Version 3.0.34) Service Manual / Issue B / 11-2017 / ac.
3.1.2.1 Sensor Information Menu
In this menu different information can be displayed about the defined input sensors on the crane.



MAIN
WORKING
SCREEN
OP-MODE
CONFIRM
INFORMATION
SELECTION
SENSOR
INFORMATION
Digital Input Information
(see Section 3.1.2.1.1)
Analog Input Information
(see Section 3.1.2.1.3)
Digital Output Information
(see Section 3.1.2.1.2)
Not available for this project
NOTE
Available screens will vary depending upon system configuration!
Function Keys
