3 After the completion of the setting, when Back is pressed, the screen
returns to the maintenance menu.
Conditions set by the ink type*1
Nozzle size Ink type
Excitation
frequency
(kHz)
Excitation
curve
Operating
temperature
upper limit (
o
C)
Operating
temperature
lower limit (
o
C)
JP - K67 68.9 01 45 0
JP - K69 68.9 02 45 0
JP - K26 68.9 05 35 0
JP - K27 68.9 06 45 0
JP - R27 68.9 07 35 0
JP - G27 68.9 08 35 0
JP - B27 68.9 09 35 0
JP - K28 68.9 10 35 0
JP - K33 74.0 13 35 0
JP - K60 68.9 14 35 0
JP - K61 68.9 15 35 0
JP - K62 68.9 16 35 0
JP - F63 68.9 17 35 0
JP - T64 68.9 18 35 0
JP - K65 68.9 19 35 0
JP - R65 68.9 20 35 0
JP - K68 68.9 21 35 0
JP - K70 68.9 22 35 0
JP - T71 68.9 23 35 0
JP - K72 68.9 24 40 0
JP - T75 68.9 26 35 0
JP - R76 68.9 27 35 0
JP - K77 68.9 33 35 15
JP - E78 68.9 34 35 10
JP - F80 68.9 35 35 0
JP - K81 68.9 37 35 0
JP - B82 68.9 36 35 0
JP - K83 68.9 40 35 0
JP - K84 68.9 28 35 0
JP - B85 68.9 43 35 0
JP - K86 68.9 38 35 0
JP - K87 68.9 39 40 0
JP - K88 68.9 45 35 0
JP - K90 68.9 41 35 0
JP - Y91 68.9 29 35 0
JP - F92 68.9 42 35 0
JP - Y94 68.9 44 35 0
JP - B95 68.9 47 35 0
JP - F97 74.0 55 35 0
JP - K101 68.9 54 40 0
JP - K106 68.9 56 35 0
65 µm
Note: *1 When the ink type is set, an initial value is automatically set.
With respect to full details about the excitation curve, refer to the
attached figure 8.6.
*2 The excitation curve value that has been initially set can be changed later.
If excitation curve “00” has been chosen, a constant value irrelevant to
the ambient temperature will be output with the “Excitation V Update”
screen (see the table below). If the excitation curve is set to a
value other than the initial one, printing may be abnormal: After
finishing maintenance work, reset the value to the original.
PH-D TYPE
Constant excitation voltage output values (set on the “Excitation V update” screen)
Setting value 00 01 02 03 04 05 06 07 08 09
Excitation voltage (V) 90 104 118 133 147 161 175 189 204 218
Setting value 10 11 12 13 14 15 16 17 18 19
Excitation voltage (V) 232 246 260 275 289 303 317 331 346 360
2-5
