2-34
2.14 Software option setup
- Use this function when setting up software options to IJ printer.
- In order to set up options, EZJ99 board and a memory card (IJP system-data is stored)
are required.
- Perform this function when the IJ printer is in a “Stop” state.
- There are some combinations that cannot be set up simultaneously with other options.
X: Combinations that cannot be set up simultaneously with other options
1 Install the EZJ99 board.
2 Insert the memory card which IJP system-data is stored.
3 Turn on the power.
4 Press Option setup at the second page of the service maintenance work
screen.
When Prev.menu and Next menu are not displayed in the maintenance work menu,
set to the service personnel maintenance mode by the password protection.
When a memory card which IJP system-data is stored is not set, Option setup
button is not displayed.
With respect to the
password protection, refer
to "2.1 setting of service
personnel maintenance
mode".
To Next Page
