3-26
3.3.4 EZJ99 board (Optional board)
[Function]
Serves as an optional signal interface for the host equipment.
[Note at the setting]
- Confirm the included parts, and set it in accordance with setting procedure.
[Included parts]
[Setting procedure]
(1) Save the current data to Memory card .
(2) Turn the power off.
(3) Remove electrical component cover (fixed by the two screws), and the plastic plate
from the bottom it.
To Next Page
