Status/Activity (Per Port) Meaning
Status Green
(On, not
ashing)
10 or 100 Mbps link present
Green O No link
Activity Amber Flashing Network activity
Amber
O No network activity
Server rear panel - models 4060, 4080, and 4100
The rear panel of these server models features numerous ports, connectors, switches,
and LEDs.
Note: Ex
cept for the ports and connectors described in the following gures,
none of the other ports or connectors should be used without guidance from
Hitachi Vantar
a Support Connect.
Figure 18 Server rear panel components for models HNAS 4060, HNAS 4080,
and HNAS 4100
Server rear panel - models 4060, 4080, and 4100
