2-102
SERVICING
(2.8 Floor Concealed Type)
Phillips ScrewdriverTool
2.8 Floor Concealed Type
2.8.1 Removing Air Filter
(1) The air filter is located at the inner upper part of the inlet.
(2) Remove the air filter by pulling the center knob and bending the filter.
TURN OFF all power source switches.
2.8.2 Removing Front Covers
(1) Remove the air filter according to the item 2.8.1 “Removing Air Filter”.
(2) Remove the front lower cover after removing ten screws at the lower part of the front cover.
Air Filter
Front Lower Cover
