12
Wireless connectivity Guide
To bind a Single Zone Thermostat (T87RF) to a Wi-Fi evohome Controller
(ATC928G3000) as the room temperature sensor in a zone...
On the evohome Controller
1
Press and hold SETTINGS for 5 seconds
2
Press the green tick
3
Press ZONE CONFIGURATION
4
Press on the required zone
5
Press TEMPERATURE SENSOR
6
Press REMOTE SENSOR
7
Press the green tick
On the Single Zone Thermostat
8
Press and hold on the left touch zone (just below
and to the left of the display) for approximately
10 seconds until a flashing ‘Bo’ is displayed
9
Turn the dial clockwise until a
flashing ‘Co’ is displayed
10
Press the left touch zone once to send the
binding signal to the evohome Controller
You should receive a message on the evohome
Controller to say the binding signal was
received. If not go back and re-bind.
Single Zone
Thermostat (T87RF)
Wi-Fi evohome Controller
(ATC928G3000)
To Next Page
