55
Central Heating Timer (ST9000RF)
Wireless Cylinder
Thermostat (CS92)
Programmer or Timer
(ST9000RF)
To bind a Wireless Cylinder Thermostat (CS92) to a Programmer
or Timer (ST9000RF) to control a hot water cylinder...
On the Programmer or Timer
1
Move the setting slider to RUN
1
Press and hold , and (right hand
side) MODE together for 8 seconds – it
should briefly show “BIND MENU”
2
Press until and SENSOR
are flashing on the display
3
Press and hold for 8 seconds to
clear any previous bind data – it should
show “RESET” for a few seconds
4
Press once
On the Wireless Cylinder Thermostat
5
Press and hold the button for 5
seconds. The green LED should come
on and the red LED should blink
6
Press the button again
You should receive a COMPLETE message on
the Programmer or Timer and the LED on the
Wireless Cylinder Thermostat should stop blinking
and turn OFF. If not go back and re-bind.
*only available on specific models and/or system configurations
