Honeywell ATC928G3000 - Wireless Relay Box (BDR91) Sundial Valve

33
evohome Controller (ATC928G2000)
Wireless Relay Box
(BDR91) Sundial Valve
To bind a Wireless Relay Box (BDR91) to an evohome Controller
(ATC928G2000) to control a Sundial valve (hot water or heating)...
On the evohome Controller
1
Press and hold SETTINGS for 5 seconds
2
Press the green tick
3
Press SYSTEM DEVICES
4
Press the button next to “Sundial Valves:”
5
Press STORED HOT WATER
6
Press HOT WATER VALVE BINDING
or HEATING VALVE BINDING
On the Wireless Relay Box
7
Press and hold the button for 15 seconds
(until the red LED blinks rapidly) to
clear any previous binding data
8
Press and hold the button again for 5
seconds (until the red LED blinks slowly)
On the evohome Controller
9
Press the bind button
You should receive a SUCCESS message
on the evohome Controller and the LED on
the Wireless Relay Box should stop blinking
and turn OFF. If not go back and re-bind.
evohome Controller
(ATC928G2000)
