CHAPTER
10
Voyager XP User Guide 197
PRODUCT SPECIFICATIONS
Voyager XP 1470g Scanner Product Specifications
Parameter Specification
Mechanical
Height 3.23 in. (82mm)
Length 2.45 in. (62mm)
Width 6.65 in. (169mm)
Weight 4.6 oz. (130g)
Electrical
Input Voltage 4.0 - 5.5VDC
Operating Power 2W (400mA @ 5VDC)
Standby Power .45W (90mA @ 5VDC)
Illumination White color (CCT 2700K)
Aiming Red color, 624nm peak wavelength
Environmental
Operating Temperature 32°F to 122°F (0°C to 50°C)
Storage Temperature -40°F to 140°F (-40°C to 60°C)
Humidity 5 to 95% non-condensing
Drop Operational after 30 drops to concrete from 5.9 ft. (1.8m)
Environmental Sealing IP40
Light Levels 0 to 100,000 lux (9,290 foot-candles)
ESD 15kV Air, 8kV contact
