Specialized features
This section describes specialized Experion features that may be of use in your system.
Feature Comments
Recipes
The Recipe Manager allows you to quickly reconfigure standard
processes.
Point Control
Schedules
Point Control Schedules enable you to control points on a periodic or one-
off basis.
Honeywell Digital
Video Manager
Honeywell Digital Video Manager is a Closed Circuit Television product
that can be easily integrated with Experion.
Recipes
The Recipe Manager allows an operator to quickly reconfigure a unit—such as a chemical
cracker or production line. The Recipe Manager achieves this by downloading a set of
predefined values to the unit.
If you have several identical units, operators can download the same recipe to any unit. If
appropriate, they can also download scaled values—to control, for example, the size of a
production batch.
A recipe can include up 30 ingredients (an ingredient specifies a value and the parameter to
which it is downloaded). If more than 30 ingredients are required, you can chain recipes
together to form a larger recipe. If you require a more sophisticated batch system, ask your
Honeywell representative for information about Experion Batch Manager.
The total number of recipes that can be configured depends on the size of your Experion
database.
Point requirements in recipes
The following naming rules apply to points used in recipes:
n The unit's two-character identifier is used as the prefix.
n The ingredient's name is used as the suffix.
n The names must follow the standard point naming conventions.
When downloading a recipe, Experion determines each point ID by combining the unit ID
and the ingredient name. The following figure shows what happens when recipe 15 is
downloaded to unit L7. In this example, the value of WATER is downloaded to the SP of
point L7WATER.
Specialized features
Honeywell 2017 109
