Honeywell 30 Series IP Cameras User Guide
Live View Tool Bar
From the Live View toolbar, you can zoom in on a scene, take a snapshot, or manually
record video. These controls are described in detail below.
Figure 18 Live View Window Controls
Table 1 Live View Window Controls
Icon Description
Click to turn on the audio to listen to the monitoring site. Click it again to
turn off the audio. The audio button is grey in the Chrome browser.
Click to switch to the full screen mode. Press Esc on the keyboard or double
click the screen to switch to the normal mode.
Click to auto fit the image. This function is not applicable in the Chrome
browser.
Click and uncheck Disable digital zoom to enable the zoom operation. The
navigation screen shows the part of the image being magnified. To resize
the navigation area, put the cursor on a border and drag the border. To
move to a different area you want to magnify, drag the navigation screen. To
zoom the image, scroll the mouse wheel. This function is not applicable in
the Chrome browser.
Click to record the video clip in MP4 file format and save it to your
computer. You can play the video clip by VLC player.
Click the button again to stop recording. When you exit the web browser,
video recording stops accordingly.
• If you run the Internet Explorer as administrator and this is the first
time you record, the recording will be stored under C:\Record.
• If you run the Internet Explorer as non-administrator, a pop-up window
will be displayed for you to select the destination.
If you have selected the storage path as non-administrator, and then you
run the Internet Explorer as administrator, the recording will be stored in
your previously selected path.
Click to capture and save video images. The captured images will be
displayed in a pop-up window. Right click the image and select Save
picture as to save it in JPEG (*.jpg) or BMP (*.bmp) format.
Language
To switch a language, click as shown in Figure 17.
User Account
To configure user account or log out the current account, click as shown in Figure
17 and the following figure is displayed:

Honeywell HC30W45R3 Specifications

General

Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired & Wireless
Wide Dynamic Range (WDR)	Yes
Maximum operating distance	30 m
IK code	IK10
Form factor	Spherical
Mounting type	Ceiling/wall
Product color	Black, White
International Protection (IP) code	IP66
White balance	Auto, Manual
Minimum illumination	0.03 lx
Bit rate control	Constant Bit Rate (CBR)
Total megapixels	5 MP
Gain control type	Auto
Maximum resolution	2560 x 1920 pixels
Video formats supported	H.264, H.265
Analog signal format system	NTSC, PAL
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1280 x 960, 1600 x 1200 (UXGA), 2048 x 1536 (QXGA), 2560 x 1920
Sensor type	CMOS
Number of sensors	1
Optical sensor size	1/2.7 \
Lens diameter	2.8 mm
Fixed focal length	2 mm
Maximum aperture number	2
Wi-Fi	No
Number of users	10 user(s)
Ethernet interface type	Gigabit Ethernet
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	256 GB
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	6.49 W
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 90 %
Windows operating systems supported	Windows 10, Windows 7

Weight and Dimensions

Depth	89.51 mm
Width	117.11 mm
Weight	540 g
Package weight	880 g
