Honeywell HC30W45R3 User Manual

51
Honeywell 30 Series IP Cameras User Guide
HTTPS
Go to Setup  Network Setup  HTTPS  HTTPS.
This section explains how to enable authentication and encrypted communication. It
helps protect streaming data transmission over the Internet on higher security level.
Figure 59 HTTPS
HTTP & HTTPS: Check to enable the web browser to be accessed via HTTP or HTTPS.
HTTPS only: Check to enable the web browser to be accessed via only HTTPS with
higher security level. This option is selected by default.
Certificate Request
Go to Setup  Network Setup  HTTPS  CERTIFICATE REQUEST.
You can fill in certificate information and the certificate request file can be exported to
the certificate issuing authority for signing and then being imported to camera.
Figure 60 Certificate Request
Enter the information of Country, State or province, Locality, Organization and
Organization unit. Click CREATE.
Click EXPORT to export the certificate request to your local computer. After you get the
signing certificate from the certificate issuing authority, click CHOOSE FILE and
UPLOAD to import it to the camera. The imported certificate will replace the original
self-signed certificate of the camera.
After the certificate file is uploaded successfully, if you want to remove the certificate,
click REMOVE.
Upload files
Go to Setup  Network Setup  HTTPS  UPLOAD FILES.

Honeywell HC30W45R3 Specifications

General

Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired & Wireless
Wide Dynamic Range (WDR)	Yes
Maximum operating distance	30 m
IK code	IK10
Form factor	Spherical
Mounting type	Ceiling/wall
Product color	Black, White
International Protection (IP) code	IP66
White balance	Auto, Manual
Minimum illumination	0.03 lx
Bit rate control	Constant Bit Rate (CBR)
Total megapixels	5 MP
Gain control type	Auto
Maximum resolution	2560 x 1920 pixels
Video formats supported	H.264, H.265
Analog signal format system	NTSC, PAL
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1280 x 960, 1600 x 1200 (UXGA), 2048 x 1536 (QXGA), 2560 x 1920
Sensor type	CMOS
Number of sensors	1
Optical sensor size	1/2.7 \
Lens diameter	2.8 mm
Fixed focal length	2 mm
Maximum aperture number	2
Wi-Fi	No
Number of users	10 user(s)
Ethernet interface type	Gigabit Ethernet
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	256 GB
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	6.49 W
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 90 %
Windows operating systems supported	Windows 10, Windows 7

Weight and Dimensions

Depth	89.51 mm
Width	117.11 mm
Weight	540 g
Package weight	880 g
