Honeywell HC30W45R3 User Manual

28
Honeywell 30 Series IP Cameras User Guide
Figure 34 Mode Tab 3
1080P FULL HD (16:9) (MAX 30fps): Select it and the maximum resolution will be
1920x1080. The aspect ratio will be 16:9. This mode applies to HC30W42R3/
HC30WB2R1/HC30WE2R3 cameras (see Figure 34).
Video Stream
Go to Setup  Camera Setup  Video  STREAM.
See the following table for streams and frame sizes of each model:
Table 4 Stream and Frame Size Matrix
Model Main Stream Sub Stream Third Stream
HC30W42R3
1920×1080/1600x904/1360x768/12
80x720/640x360
1280x720/640x360
640x360
HC30W45R3
(4MP)
2688x1520/1920x1080/1600x904/1
280x720/640x360
1280x720/640x3
60
640x360
HC30W45R3
(5MP)
2560x1920/2048x1536/1600x1200/
1280x960/800x600/704x480/640x4
80
800x600/704x48
0/640x480
640x480/70
4x480
HC30W45R2
(4MP)
2688x1520/1920x1080/1600x904/1
280x720/640x360
1280x720/640x360 640x360
HC30W45R2
(5MP)
2560x1920/2048x1536/1600x1200/
1280x960/800x600/704x480/640x4
80
800x600/704x48
0/640x480
640x480/70
4x480
HC30WB2R1
1920×1080/1600x904/1360x768/12
80x720/640x360
1280x720/640x3
60
640x360
HC30WB5R1
(4MP)
2688x1520/1920x1080/1600x904/1
280x720/640x360
1280x720/640x3
60
640x360
HC30WB5R1
(5MP)
2560x1920/2048x1536/1600x1200/
1280x960/800x600/704x480/640x4
80
800x600/704x48
0/640x480
640x480/70
4x480
HC30WB5R2
(4MP)
2688x1520/1920x1080/1600x904/1
280x720/640x360
1280x720/640x3
60
640x360
HC30WB5R2
(5MP)
2560x1920/2048x1536/1600x1200/
1280x960/800x600/704x480/640x4
80
800x600/704x48
0/640x480
640x480/70
4x480
HC30WE2R3
1920×1080/1600x904/1360x768/12
80x720/640x360
1280x720/640x3
60
640x360
HC30WE5R3
(4MP)
2688x1520/1920x1080/1600x904/1
280x720/640x360
1280x720/640x3
60
640x360
HC30WE5R3
(5MP)
2560x1920/2048x1536/1600x1200/
1280x960/800x600/704x480/640x4
80
800x600/704x48
0/640x480
640x480/70
4x480
HC30WE5R2
(4MP)
2688x1520/1920x1080/1600x904/1
280x720/640x360
1280x720/640x3
60
640x360

Honeywell HC30W45R3 Specifications

General

Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired & Wireless
Wide Dynamic Range (WDR)	Yes
Maximum operating distance	30 m
IK code	IK10
Form factor	Spherical
Mounting type	Ceiling/wall
Product color	Black, White
International Protection (IP) code	IP66
White balance	Auto, Manual
Minimum illumination	0.03 lx
Bit rate control	Constant Bit Rate (CBR)
Total megapixels	5 MP
Gain control type	Auto
Maximum resolution	2560 x 1920 pixels
Video formats supported	H.264, H.265
Analog signal format system	NTSC, PAL
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1280 x 960, 1600 x 1200 (UXGA), 2048 x 1536 (QXGA), 2560 x 1920
Sensor type	CMOS
Number of sensors	1
Optical sensor size	1/2.7 \
Lens diameter	2.8 mm
Fixed focal length	2 mm
Maximum aperture number	2
Wi-Fi	No
Number of users	10 user(s)
Ethernet interface type	Gigabit Ethernet
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	256 GB
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	6.49 W
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 90 %
Windows operating systems supported	Windows 10, Windows 7

Weight and Dimensions

Depth	89.51 mm
Width	117.11 mm
Weight	540 g
Package weight	880 g
