Page #43 background imageLoading...
Page #43 background image
7.1.7 Remote Reset, Continued
b. Select the “camera to reset” by pressing the number buttons for the
corresponding camera, and then press the camera button. Note: if you select a
camera that is absent, the display returns to camera 1.
c. Press aux to reset the selected camera.
d. Select another camera or press lock to exit.
7.2 MONITORS
To access the monitors menu:
MAIN MENU
1 CAMERAS
2 MONITORS
3 SYSTEM
4 ALARMS
5 SOFTWARE
MONITOR MENU
1 AUTO-SEQUENCE
2 PARTITIONING
3 TEXT BRIGHTNESS
SELECT OPTION
LOCK TO EXIT
1. Access the main menu by pressing the 9 button,
the 0 button, the 9 button, the 0 button, and then
pressing the lock button.
2. Access the monitors menu, by pressing the 2
button.
7.2.1 Auto-Sequence
From the monitor menu, press the 1 button to
program monitor auto-sequences.
AUTO-SEQUENCE SETTINGS
STEP CAMERA DWELL
01 01:FRONT DOOR 5
02 02:BACK DOOR 5
03 03:SIDE DOOR 5
04 04:CAR PARK 5
05 05:SHOP FLOOR 5
06 06:OFFICE 5
AUX TO SET END OF SEQUENCE
LOCK TO EXIT
1. Use the joystick (up, down, left, and right) to
select the desired fields and enter data
using the number buttons on the keyboard.
The camera number range is from 1 to the
maximum number of cameras in the system.
The dwell range is from 1 to 255 and defines
the length of time (in seconds) that the
camera will be displayed for during the
sequence.
Note: camera titles shown above are
for illustrative purposes only.
Rev. 1 31 900.0560
18-July-2005
