- 32 -
4~20mA) is selected.
z
The set range is -19999 to 20000(LOW < HIGH).
z
It can be changed according to decimal point and setting the scale ra
nge like the
below table.
Maximum and Minimum sca
le
-19999 ~ 20000
Scale is 0 to 1000
Decimal
Point
Low High
Low
High
0 -19999
20000
0
1000
1 -1999.9
2000.0
0.0
100.0
2 -199.99
200.00
0.00
10.00
3 -19.999
20.000
0.000
1.000
