Honeywell IPC5000 User Manual

- 31 -
Instrument input range
Input type
Input
range
code
DEG C DEG F
K1 -200.0~200.0 -328.0~392.0
K2 0.0 ~ 1200.0 32.0~2192.0
K3 0.0~800.0 32.0~1472.0
K4 0.0~400.0 32.0~752.0
K
K5 0.0~1316.0 32.0~2400.0
J(IC)
J 0.0~800.0 32.0~1472.0
R
R 0.0~1600.0 32.0~2912.0
S
S 0.0~1600.0 32.0~2912.0
B
B 0.0~1800.0 32.0~3272.0
E
E 0.0~800.0 32.0~1472.0
T
T -200.0~300.0 -328~572.0
N
N 0.0~1300.0 32~2372
W1 W1 0.0~1200.0 32~2192.0
W2 W2 0.0~2300.0 32~4172
Thermo
couple
C C 0.0~2300.0 32~4172
z If the button(4) is pushed, Figure 3.3.2 appears and you can select the sensor type
in the screen.
z If the sensor type is changed, the PV and SP low/high limit range is adjusted
automatically according to the range of the selected sensor type.
(2-3) Dec. P. (decimal point) setup: Places Decimal point indication
z Decimal point of Thermocouple and RTD type is 0 ~ 2, Default = 1
z Volt and mA type is from 0 ~ 3, Default = 1
z If the sensor type is changed, the decimal point is one.
(3) Sensor Select.
They are listed by sensor input type and setup range.
After pushing UP and DOWN arrow buttons and selecting the sensor type, if you push the “OK”
button, the sensor type is set and if you push the “CANCAL” button, it is canceled.
If you press the ‘PAGE’, 7 items of the sensor types are shown.
(4) SENSOR TYPE Setup Button: Screen switching
z Switch to ’SENSOR SELECT’ screen (Fig 3.3.2 ).
(5) SCALE LH(Low – High)
z The high and low range of the Linear input type(Volt/Current) is set.
z This set area is displayed, if the Volt/Current(0~10V, 0~5V, 1~5V, 0~20mA,
