- 84 -
z Input/output specifications
Items Specification
Number of inputs 2 (Universal input)
Type
TC: K, J, R, S, B, E, T, N ,W,C(JIS/IEC)
RTD: Pt100 (JIS/IEC), JPt100 (JIS)
Linear:
VOLTAGE 0~10V, 0~5V, 1~5V
CURRENT 0 ~ 20mA, 4 ~ 20mA
For detail, refer to Table 2.6.1
Sampling cycle 100 ms/channel
Indication Accuracy
±0.1%FS±1digit (Accuracy is variable according to input type
or range.)
Cold junction accuracy ±1.0 ºC (±1.8 ºF) (under standard conditions)
Input bias -99.9 ~ +99.9 variable
Digital filter 0 ~ 120 sec (0: filter off)
Square-root Extraction
Low-cutoff: 0.1~5.0% of input (in case of voltage input from
orifice or pressure sensor)
Analog
input
Compensation
Linearity / Approximation
(1)Segment breakpoint: 1 to 10 of total range
(2)Compensation: -50.0~105.0% of CH1/2 PV input range
(3)Bias
Linearity : -50.0~105.0% of CH1/2 PV input range span
Approximation: -50.0~105.0% of CH1/2 PV input range
Input count 12 points
Connectable output type
No-Voltage contact (relay contact) and Open collector (sink
current toward 0V)
Allocation (Fixed)
RUN/STOP, ADV, HOLD, Channel selection, Trouble inputs,
Program number (or detail, refer to Table 2.6.2)
Sampling cycle 100 ms
External
switch input
Trouble messages 32 items
