Honeywell IPC5000 User Manual

- 85 -
Items Specification
External supply
voltage
MAX 30Vdc
Open collector
output
Max. load current MAX 100mA per channel
Output Open collector x 12 (variable)
Event output
Time event
Event mode
3 types can be selected (depending on number 0,
1 and 2 input) only for Program segment.
0: OFF, 1: ON, 2: ON/OFF time setting
Output points
Open collector output ON/OFF x 12 (Changeable)
(MAX DC30V MAX 100mA / 1ch internal
resistance 47Ω)
Event mode According to number of 11 ~ 38
Operation channel Loop1 /Loop2
Target value
Set Point (SP) / Present value (PV) / Target value
(DV) / Manipulated value(MV)
Operating point Absolute value (ABS) / Deviation (DEV)
Output operation ZONE ON/OFF / Operation direction (LOW/HIGH)
Loop1 Loop2
Absolute
value
-19999.0 ~
20000.0
-19999.0 ~
20000.0
Deviation
value
-99.9 ~ +99.9 -99.9 ~ +99.9
Operation Range
Operational
point
± 0.0 ~ ± 100.0 ± 0.0 ~ ± 100.0
Event output PV events
On delay time 0 ~ 99 seconds
Output type
STOP,RUN,READY,END,TRBL,HOLD,WAIT,
TUNE,MAN,FIX,DOWN,UP
Event mode According to number of 41~60
Output points
Open collector output ON/OFF x 12 (Changeable)
(MAX DC30V MAX 100mA / 1ch internal
resistance 47Ω)
Target Loop 1 /Loop 2 /BOTH
Event output Mode event
Condition
OR: When Loop 1 or Loop 2 is occurred , output
AND: When Loop 1 and Loop 2 are occurred,
output
