z Program specifications
Items Specification
No. of programs 100 programs (0 ~ 99)
No. of segments 100 segments/1 program, or total 2000 segments
Segment setting system
Segment time: Set by set points (SP) and time
(Max. 99hours59min or 99min59sec)
Segment Ramp-unit:
Soaking-segment ramp rate (hr.min/min.sec)
Ascending/descending ramp (Slope per hour/min)
* Time unit is switchable
PID group setting
Using segment PID
Using zone PID: According to PV
According to SP
Group No.: 1 to 8
WAIT function
(Guarantee Soak)
Type (Front, rear, all) and WAIT zone and WAIT time
Repeat
1 pattern all repeat x 1 (Maximum repeat is 999 cycle)
Part repeat x 5 (Maximum repeat is 999 cycle)
PV Start
Starting Target Set Point (SSP1 or SSP2)
Starting with PV data point: Program operation starts with the
PV data at the time of starting and advances toward the target
Set Point of segment-1 for both PV1 and PV2 programs
Event setup TIME and PV events setup are available. Max 2000 items.
Program link
Maximum 6 programs
Link program registration: Maximum 10 links
Program name
100 programs (Each pattern can have its name), Max. 12
characters
Program section
POWER FAILURE
Controls right away after recovery of power failure, if the power
failure lasts less than 5 seconds.
For power failure that lasts longer than 5 seconds, setup
modes below will be followed.
BREAK
: Stops program
HOT
START: Controls at the state just before power failure
COLD
START: It starts again at the beginning of program
(Note) It is HOT START for fix control
