Honeywell IPC5000 User Manual

- 88 -
z Control output specifications
Items Specification
Algorithm PID-A / PID-B / DUP-A / DUP-B
Proportional band (P)
Proportional Band: 0.1 ~ 9999%
GAIN: 0.001 ~ 1000
Integral time (I) 0.00 ~ 10.00 RPT/MIN
Derivative time (D) 0.02 ~ 50.00 RPT/MIN
Manipulated variable limit
(MV)
Low-limit: -5.0 to High-limit %
High-limit: Low-limit to +105.0%
Manual reset –100 to +100
No. of PID groups
Loop 1: 8 groups
Loop 2: 8 groups
PID groups selection
Segment specified, automatic
zone selectable during program
run
Auto tuning
Accutune II: Automatic setting of
PID value by limit cycle method.
Fuzzy Control function Fuzzy Control function
PID control
On-off control differential 0 ~ 1000
Control direction
Selection is settable (Reverse/Direct)
HEAT/COOL is settable each channel
Control Section
Operation mode
Auto/Manual operation is switchable
*Manual output : i) Bumpless
ii) Preset value : -5.0~105.0%
Output set TYPE Current, Voltage Pulse, Relay
Output signals 4~20mA DC
Output accuracy +/-0.1% of span
Current output
Output update cycle 100 msec
Open time terminal
voltage
Lower than 15V DC (20mA)
Voltage output
Time proportional cycle 1 ~ 240 sec
Output signal
NC, NO, and common terminals
(SPDT)
Relay contact
Output
Contact rating
250VAC, 3A or 30VDC, 3A
(Resistance load)
External Supply Voltage MAX DC30V
Control output
section
Open Collector
Max. Load Current MAX 100mA/1ch
