Honeywell IPC5000 User Manual

- 89 -
z Control mode
Items Specification
READY: It ready until scheduled time (Control stop)
RUN: Advancing run state
HOLD: Hold run state
WAIT: Wait run state
END: End point run state (Control stop)
BREAK: POWER FAILURE mode and Stop state(Control stop)
TUNE: AUTO-TUNING state
Program run mode
QUICK: Start by RUN/STOP key or contact relay input
TIMER: Start by scheduled time
READY: It ready until scheduled time(Control stop)
RUN: Advancing run state
HOLD: Hold run state
TUNE: AUTO-TUNING state
Mode
Fix control mode
QUICK: Start by RUN/STOP key or contact relay input
TIMER: Start by scheduled time
z Communication specifications
Items Specification
Speed 9600 or 19200
Parity check NONE
Bit length 8
RS232 (Basic)
Stop Bits 1
Bit transfer
order
LSB first
ModBus (Option)
Number of data bits
per character
End of
message
Idle line for three or
more characters (>1.56
msec).
Protocol ModBus / TCP protocol
Port One 10BaseT(RJ-45 connector)
Communication
Ethernet (Option)
Cabling type
UTP category 2 or better
Note) UTP: Unshielded Twisted Pair cable

Honeywell IPC5000 Specifications

General

Brand	Honeywell
Model	IPC5000
Category	Controller
Language	English
