Honeywell MPA2C3 Installation Manual

CHAPTER
6
MPA2C3 Installation Guide 143
HARDWARE SPECIFICATIONS
The specifications in this section apply to panels of both the standard metal enclo-
sure and compact plastic enclosure.
Feature list MPA2C3 2-door panel
MPA2 Technical Data
Technical data MPA2MPSE OR MPA2MPSU
Operating voltage range and frequency 100-240V AC, 50/60 Hz
Power Supply current consumption 1.1 A
Power Supply output voltage 13.8 V
Power Supply output current 3.3A
Power Supply output ripple max 138 mV peak to peak
Protection class per EN 60529 IP42
Operating temperature range -10°C ~ +45°C (including battery)
Storage temperature range -40°C ~ +85°C
Relative humidity 5% ~ 96% RHNC
Weight with MPA2C3 5.8 kg
Dimensions 410(h) x 360(w) x 120(d) mm
Technical data MPA2C3
Operating power from 13.8VDC Power Supply Unit)
