MPA2C3 Installation Guide 37
Wiring the Door Peripherals
Information Card
The MPA2C3 contains an information card as shown below.
The information card represents the reader, door, inputs, and outputs connections,
power and battery input, Ethernet and USB connections, RS485 bus information,
LED, DIP Switch and Jumper locations and functions.
The Information card also includes 2 QR codes. One to get the manual digitally on
your mobile device and one as a unique identifier for e.g. the Device Utility App.
Scan for Manual
Scan for Device Utility App
