MPA2C3 Installation Guide 45
Wiegand mode panel setting
The MPA2C3 2-door system Wiegand mode can manage up to 4 readers to support
2 doors with IN and OUT readers per door.
Note: Any Wiegand reader is supported for either 2-door or 4-door configuration. There is no
need for Wiegand hold wire supported readers.
Note: For retrofitting Wiegand hold wire configurations from MPA2C1 and MPA2C1-4, the
reader can be reused in the original MPA2C1 or MPA2C1-4 configuration. The hold
wire control will not be used in the MPA2C3 and will be in a state, that the reader will
function as normal.
To set up the MPA2C3 in Wiegand mode per door DIP Switch
Table 3-3 settings and Jumper
• RDR 1 (JP13/JP14) and RDR 2 (JP15/JP16) both jumpers must be set
synchronized
Once the reader terminals have been set to Wiegand mode correctly, the two LEDs
on the RJ45 connector will have the following function:
• Left yellow LED
• Idle: OFF
• Card reading and transmitting to panel: flashing
Right green LED : OFF
MPA2C3
(2 Door)
DIP Switch Jumpers* Reader
Reader
Mode
SW1 SW2 RDR 1 RDR 2 Reader mode
READER
Function
Wiegand
(DEFAULT)
Bit 1: OFF
(OSDP1)
Bit 1&2: OFF
(EOL
OSDP1)
Enable 1-
2
(Wieg.A/
B)
READER 1 IN
Wieg.A / OSDP 1
Door1 IN reader
READER 1 OUT
Wieg.B / OSDP
1
Door1 OUT reader
Bit 10: OFF
(OSDP2)
Bit 3&4: OFF
(EOL
OSDP2)
Enable 1-2
(Wieg.A/B)
READER 2 IN
Wieg.A / OSDP 2
Door2 IN reader
READER 2 OUT
Wieg.B / OSDP
2
Door2 OUT reader
