WIRING THE PANEL AND DEVICES
The connectors on the control panel are designed in multiple colors to make easy
connections.
Shutting down and Restart the Panel
Shutting down the Panel
Figure 3-1 Pressing the SHUTDOWN Button
The SHUTDOWN button allows you to shut down the control panel securely. This
ensures that the system can save all necessary data and status in the flash mem-
ory. Shutting down the panel disables the inputs/outputs, turns OFF the peripheral
bus, AUX outputs and the PTCs. However, it cannot remove power from the panel
(from the AC power adapter or the batteries).
