Honeywell MPA2C3 Installation Manual

MPA2C3 Installation Guide 27
Figure 2-4 Power Supply
Supervised and Non-Supervised Input Wiring
The supervised inputs are locate on the following terminal blocks:
Table 2-2 Table 5 Supervised Input Terminal Blocks/RJ45
PoE+ Switch
Battery
Board Configuration Terminal Block RJ45
Battery 12V/7A~12Ah
Main Board Rdr/Door 1 connector DOOR 1 / AUX1
GND, DrCnt1
GND, DrCnt AUX1
DOOR 1/ DOOR 3
GND, DrCnt1
GND, DrCnt3
DOOR 1
Pin 4: GND, Pin 2: DrCnt1
AUX 1
Pin 4: GND, Pin 2: DrCnt AUX1
DOOR 3
Pin 4: GND, Pin 2: DrCnt3

Honeywell MPA2C3 Specifications

General

Brand	Honeywell
Model	MPA2C3
Category	IP Access Controllers
Language	English
