MPA2C3 Installation Guide 147
Feature list MPA2C3 4-door panel
Hardware specifications for MPA2C3 4-door panel are listed in the below table
technical data MPA4MPSE OR MPA4MPSU are the same as listed for MPA2MPSE
or MPA2MPSU.
Technical data MPA2C3-4
Operating power from 13.8VDC Power Supply Unit)
Rated operating voltage + and -
10 ~ 19 VDC
13.8VDC
Operating voltage range 10VDC ~ 19VDC
Max ripple voltage max 1.0 V peak to peak
Current consumption with Ethernet
without external loads
200mA @ 13.8VDC
260mA @ 13.8VDC (FACP in use)
Max current output to all peripherals
combined when powered by Mains
All 12V internal outputs and busses 3A
Battery (Only with 13.8VDC Power Supply Unit)
Battery type
+ and -
Battery
12V
7Ah ~ 12Ah
12V Lead-Acid Batteries in acc. with
IEC 60896-21 / 60896-22
Battery capacity 7Ah ~ 12Ah
Number of connectable Batteries 1
Max Battery load current 512mA
Battery shutdown voltage 10.5V
Operating power from Power over Ethernet (PoE+)
Rated operating voltage Eth1 PoE+ / HOST @ RJ45 42.5-57V
Operating voltage range according to IEEE 802.3at
Available Power 25.5W
Current consumption with Ethernet
without external loads
300mA @ 11.5VDC
375mA @ 11.5VDC (FACP in use)
Max current output to all peripherals
combined when powered by PoE+
All 12V internal outputs and busses 1800mA @ 11.5VDC
Panel Power consumption
Each EOL resistor for monitored
input will extend current
consumption by
DrCnt Door 1-4,
Rex Door 1-4,
Aux Inputs IN 9-16
1mA per monitored input
Each relay activation will extend
current consumption by
OUT 1-4,
Aux Outputs 5-8
15mA per relay
Maximum current consumption for
RS485/OSDP bus
current
OSDP1, OSDP2 500mA per bus
