Honeywell MPA2C3 Installation Manual

MPA2C3 Installation Guide 149
Output Contact type OUT 1-4 Selectable per jumper OUT1-4: NO
(Normally Open) or NC (Normally Closed)
Aux Outputs 5-8 NO (Normally Open)
Relay contact max switching voltage
and current
(dry contact)
OUT 1-4 @ RJ45 500mA @ 30VDC,
500mA @ 22VAC
OUT 1-4 @ push in terminal
block**,
Aux Outputs 5-8
3A @ 30VDC,
1A @ 22VAC
Max output Voltage at Door 1/3
output when OUT1, OUT3 jumper
onboard "12V” is used (wet contact)
OUT 1 @ RJ45 or
OUT 1 @ push in terminal block**,
OUT 3 @ RJ45 or
OUT 3 @ push in terminal block**
10VDC ~ 14VDC
Max output current at Door 1/3
output when OUT1, OUT3 jumper
onboard "12V” is used (wet contact)
OUT 1 @ RJ45 **,
OUT 3 @ RJ45 **
500mA per RJ45, limited to 750mA @
12VDC combined over both door output
contacts
OUT 1 @ push in terminal block**,
OUT 3 @ push in terminal block**
750mA @ 12VDC combined over both door
output contacts
Max output Voltage at Door 2/4
output when OUT2, OUT4 jumper
onboard "12V” is used (wet contact)
OUT 2 @ RJ45 or
OUT 2 @ push in terminal block**,
OUT 4 @ RJ45 or
OUT 4 @ push in terminal block**
10VDC ~ 14VDC
Max output current at Door 2/4
output when OUT2, OUT4 jumper
onboard "12V” is used (wet contact)
OUT 2 @ RJ45 **,
OUT 4 @ RJ45 **
500mA per RJ45, limited to 750mA @
12VDC combined over both door output
contacts
OUT 2 @ push in terminal block**,
OUT 4 @ push in terminal block**
750mA @ 12VDC combined over both door
output contacts
Relay contact min switching voltage
and current
OUT 1-4, Aux Outputs 5-8 1mA @ 5VDC
** Connect either RJ45 or push in terminal block; do not connect same Door output on both RJ45 and push in terminal
block.
Inputs
Supervised Input range DrCnt Door 1-4,
Aux Inputs IN 9-16
2k2Ohm +-10% default,
1k, 4k7, 10k Ohm selectable. (supervised
selectable)
Digital input Rex Door 1-4 Short circuit to GND default
(Unsupervised / digital selectable)
