MPA2C3 Installation Guide 41
Table 3-2 Table for reference.
MPA2C3
Wiegand Reader
(2 door)
Reader mode RJ45 Connector
READER
 Reader Function
Wiegand
READER 1 IN
Wieg.A / OSDP 1
Door1 IN reader
READER 1 OUT
Wieg.B / OSDP 1
Door1 OUT reader
READER 2 IN
Wieg.A / OSDP 2
Door2 IN reader
READER 2 OUT
Wieg.B / OSDP 2
Door2 OUT reader
MPA2C3-4
Wiegand Reader
(4 door)
Reader mode RJ45 Connector
READER
Reader Function
Wiegand
READER 1
Wieg.A / OSDP 1
Door1 IN reader
READER 2
Wieg.A / OSDP 2
Door2 IN reader
READER 3
Wieg.A / OSDP 1
Door3 IN reader
READER 4
Wieg.A / OSDP
Door4 IN reader
