68 MPA2C3 Installation Guide
In order to test the addresses of the set OSDP readers, you can use any compatible
card, keyfob or credential for that reader. The credential does not have to be valid in
the system for this function.
Select menu Panel Configuration / Advanced / Reader Addressing.
See the instruction in the web interface.
1. Apply / swipe the compatible card to the reader to be tested
2. Look into the web interface and decide if “Reader OK” at the correct address or
reader function will appear
3. See below table, indicating the Reader OK
Note: “Reader OK” will turn back into online after 10 seconds.
4. If the reader OK does not appear on the expected, edit the address / function to
the correct per the previous paragraphs
Correcting/editing reader address
Address correction can be done by correcting address of individual reader or by
resetting addresses of all the connected readers.
1. Identify readers with wrong address / wrong function
2. Disconnect all the identified wrong readers but keep one wrong reader
connected.
3. Edit its address assignment and let it come online
4. <<Figure ghi: Show screenshot assigned Reader is edited and show online
status>>
5. Disconnect the edited reader used in last step
6. Connect rest of the readers (with wrong addresses) one at a time and follow
steps 3 and 4
Example: Readers R1 and R2 installed physically at a door 1 IN and door 1 OUT are
wrongly assigned as Door 1 OUT and Door 1 IN respectively.
