72 MPA2C3 Installation Guide
In a 2-door MPA2C3 controller, each Door I/O (Input/Output) is identified with
DOOR1 and DOOR2.
The AUX1 and AUX2 I/O are not controlled as a Door I/O, however the Inputs REX
and Door Contact and Output AUX1 can be controlled as additional auxiliary
device controls.
In a 4-door MPA2C3 controller, each Door I/O (Input/Output) is identified with
DOOR1 – DOOR4.
MPA2C3 2-door peripherals configurations
Table 3-9 The connections for monitoring and locking devices
DOOR # Terminal Block
Pin
RJ45 Terminal
Pin
Function Software
Name
